| Model | Width (MM） | Length（MM） | layer | Speed | Power（KW） | Size（M） |
| 1500 | 80-1350 | 10-1500 | 1-5 | 100/min | 5 | 3300X1750X2200MM |
A 5-layer EPE foam sheet cutting machine is built for converters that receive full-width EPE roll stock and must resell or feed it as fixed-size sheets, strips or padded pieces. Instead of running one roll, slitting by hand and cross-cutting with a separate guillotine, the line unwinds up to five EPE rolls together—or processes a stacked pile—slits the web longitudinally with circular knives, cross-cuts transversely to the ordered length, and discharges counted stacks. On thin-sheet models the same pass can add punching and automatic transfer so the finished carton pack is ready without manual sorting.
Plants use it after EPE sheet extrusion, bonding or lamination when the order book contains many SKUs: protective interleavers, electronics pads, appliance liners, baby-mat blanks, insulation offcuts and e-commerce cushion pieces. The economic case is reduced handling, repeatable length/width tolerance and higher pieces per operator-hour versus single-roll manual cutting.
What a converter gets from a correctly specified 5-layer cutter
Five rolls or one stacked pile in one pass
Simultaneous feeding removes the bottleneck of re-running the same width five times. For thin EPE（0.3–3 mm per roll）, five-roll feeding is the usual configuration; for thick plank（10–80 mm single pass）, the machine is specified by total stacked height rather than “5 rolls.”
Slitting and cross-cutting without a second station
Circular knives set longitudinal strip width; the transverse knife sets cut length. Operators change recipes instead of re-marking and hand-pushing sheets. Reference combined slitter/cross-cutters handle feed widths around 1300–1600 mm with circular-knife width ranges from 25–1300 mm up to 45–1600 mm depending on model.
Servo length control, not manual guessing
Encoder/PLC length setting, servo or inverter pull, and photocell/registration where printed rolls are used keep first-piece and last-piece within tolerance. Multi-roll thin-sheet models are referenced around 100 pcs/min cross-cut depending on width and strip count; heavier combined slitter/cross-cutters are better quoted in m/min and pieces per shift from sample.
Less offcut and rework
Automatic edge trimming, NC pressing-roll height, stored knife positions and recipe call-up reduce trial cuts when switching between, for example, 300×400 mm electronics pads and 1000×2000 mm mat blanks. One PLC source lists ±0.1 mm capability for selected CNC circular/horizontal configurations; for soft multi-layer EPE, agree acceptance tolerance per foam density and knife type rather than quoting one universal number.
Optional punching and auto-transfer
Thin-sheet lines can punch handles/holes and transfer finished stacks when the counter reaches the preset quantity. This is what turns the machine from “cutter” into a finished-pad line for retail and fulfillment orders.
How the 5-Layer EPE Foam Sheet Cutting Machine runs
Multi-roll unwind / stack infeed – Five EPE rolls are mounted on synchronized shafts, or pre-stacked sheets are loaded to the set pile height. Tension/edge guide keeps layers aligned so strips stay parallel.
Longitudinal slitting – Circular knives set strip width; knife quantity and spacing are stored per SKU. Automatic trimming removes irregular edges before cross-cut.
Press/feed control – NC pressing roller sets height for the pile or combined web; servo/inverter pull feeds the set length. Recipe call-up changes width/length without manual knife remeasuring.
Transverse cross-cut – Horizontal/cold or hot knife cuts to length. For thin 5-roll pads, cross-cut and slitting can run in one cycle; for thick plank, cross-cut cycle is set by thickness and blade type.
Optional punch/transfer – Punch unit makes handles/holes; counter triggers automatic stack transfer when the batch quantity is reached.
Count and pack – Meter/piece counter, batch report and off-load conveyor feed carton packing or downstream lamination/bagging.
Applications that keep the line loaded
Electronics/accessories – thin EPE pads and strips for phones, drives, cables, small appliances; antistatic masterbatch handled upstream.
Appliance and white-goods – interlayer sheets, panel liners, corner strips, remote/accessory pads.
Baby/play mats and yoga blanks – thin multi-layer cutting into printed mat blanks, then bonding/embossing downstream.
Glass/ceramics/metal parts – slitted strips and cross-cut pads for interleaving, edge protection and export cartons.
Insulation and construction offcuts – EPE/foil laminated sheets slit to wall/pipe-panel sizes; punch holes for fixing where specified.
E-commerce fulfillment – fixed-size cushion pads and mailer inserts produced in batches by SKU.
How to specify the quotation
Ask buyers for these six inputs; it prevents “5-layer machine, send price” replies that cannot be engineered.
Feeding style – five thin rolls simultaneously, stacked sheets to max pile height, or thick single-layer plank.
Material build – plain EPE gsm/thickness, density kg/m³, film/foil lamination, printed mark, EVA/XPE if included.
Sizes – strip widths, cross-cut lengths, min/max, fixed retail or random; pieces per shift/day.
Accuracy – acceptable width/length tolerance by foam density; hot vs cold vs circular knife preference.
Options – punch pattern, auto stacking, trimming, EPC, metering, downstream bonding/bagging link.
Plant data – voltage/frequency, compressed air, floor length/height, roll diameter, operators, destination port/Incoterm, certifications.
Example: “5 rolls EPE 1 mm each, density 20 kg/m³, slit 100/150/200 mm, cross-cut 300 mm, 100 pcs/min target, punch handle optional, 380V/50Hz, Egypt” → 1350-class 5-roll servo model, 5+ circular knives, cross-cut knife, punch station, auto counter/stack.
Example: “Stacked EPE plank total 60 mm, 1600 mm width, slit 50–400 mm, cross-cut 1000–2000 mm, 440V/60Hz, USA” → 1600 combined slitter/cross-cutter, NC press roller, 8 circular knives, heavy transverse knife, pneumatic 0.4–0.8 MPa, FAT on sample pile.
FAQ
What does “5-layer” mean on an EPE sheet cutting machine?
It usually means the machine can feed up to five EPE rolls together and slit/cross-cut them in one pass for thin-sheet production. Some buyers also use “5-layer” for a stacked pile of five sheets; in that case the quotation should be based on total stacked thickness and pile height, not on the number of rolls.
Can it slit and cross-cut in the same pass?
Yes. Circular knives perform longitudinal slitting while a transverse knife performs cross-cutting. Edge trimming and NC press-roll control keep strip width and cut length consistent. Heavy plank models may use a separate cross-cut cycle, so confirm knife type by foam thickness.
What EPE thickness and width can it handle?
Thin 5-roll models commonly handle each roll in the approximate 0.3–3 mm range; general EPE slitters are offered from 0.5 mm up to 100 mm single/staff thickness and combined slitter/cross-cutters around 3–80 mm, with wider custom builds. Feed width is commonly 1350 mm for 5-roll thin lines and 1300/1600 mm for combined machines, extendable to 2000 mm or wider.
What cutting accuracy can we expect?
Selected CNC combined slitters are specified around ±0.1 mm for circular/horizontal knife settings; practical multi-layer EPE tolerance depends on foam density, knife sharpness, pile height and feed tension. For procurement quotes, agree an FAT tolerance per SKU—for example width/length acceptance bands—rather than a single catalog number.
Does it support punching and automatic stacking?
Thin-sheet 5-roll models can include punching and automatic stack transfer when the piece counter reaches the preset quantity. For thick plank, stacking is usually offline or via conveyor because piece weight and cut cycle are different.
How many operators are needed?
A synchronized 5-roll line with auto stacking can run with one operator for roll loading, QC and off-load. Combined slitter/cross-cutters with manual stack removal may need one operator per shift plus helper during roll change; add labor only where piece weight or packing speed requires it.
Can it cut laminated EPE, foil-faced or printed rolls?
Plain EPE is standard. Film-laminated, foil-faced or printed EPE can be cut if blade type, pressure and speed are matched; printed rolls use photocell/registration. Send a sample roll so knife selection and tolerance are confirmed during FAT.
What after-sales do you provide for export plants?
Sample run/FAT with customer EPE where logistics allow, export packing, installation supervision, PLC/HMI training, English electrical/mechanical manuals, spare-part list（circular knives, horizontal knife, servo drivers, sensors, pneumatic seals）, and remote troubleshooting. Publish only real certifications—CE/ISO or equivalent—and quote warranty, lead time and Incoterms per contract.
